SKU: 24B-1-SD-NO12-RENOLD
Renold SD 24B-1-NO12 BS Simplex Chain Single Cranked Cottered Link 1-1/2 inch Pitch
Renold SD 24B-1-NO12 BS Simplex Chain Single Cranked Cottered Link 1-1/2 inch Pitch
Regular price
$36.98
ex VAT
Regular price
Sale price
$36.98
ex VAT
In stock
Price Break
10+
$32.91
19+
$31.06
29+
$30.69
39+
$30.32
49+
$29.95
74+
$29.58
99+
$27.74
199+
$27.37
249+
$27.00
499+
$26.63
999+
$25.89
Couldn't load pickup availability
Description
Description
| Renold No. 12 European (BS) Simplex Connecting Link: A single link with cranked plates pressed onto a bush and roller assemble at the narrow end. A clearance fit connecting pin (No. 128) is fitted at the wide end and is secured by a split pin. |
- Brand / Quality:
- Renold - High Quality
- Pitch:
- 38.1mm = 1.5 (1-1/2) inch
Technical
Technical
| Pitch (A) | 1.5 inch |
|---|---|
| Pitch (A) | 38.1mm |
| Inside Width min (B) | 25.4mm |
| Roller Diameter max (C) | 25.4mm |
| Plate Height max (D) | 33.3mm |
| Plate Width Inner max (E) | 6mm |
| Plate Width Outer max (F) | 5.2mm |
| Pin Diameter max (G) | 14.63mm |
| Pin Length max (H1) | 53.3mm |
| Connecting Link Extension max (J) | 4.2mm |
| ISO606 Tensile Strength min | 160000 N |
| Weight | 0.001kg/m |
