53207 Budget Single Thrust Ball Bearing with Spherical Housing Seat U207 35x62x22mm
53207 Budget Single Thrust Ball Bearing with Spherical Housing Seat U207 35x62x22mm
Regular price
$39.49
ex VAT
Regular price
Sale price
$39.49
ex VAT
In stock
Price Break
10+
$35.15
19+
$33.17
29+
$32.78
39+
$32.38
49+
$31.99
74+
$31.59
99+
$29.62
199+
$29.22
249+
$28.83
499+
$28.43
999+
$27.64
Description
Description
|
Thrust Ball Thrust Bearings Spherical Seat Type: These bearings consist of three parts, a shaft and housing washer that have annular grooves in them and a caged ball bearing assembly that is sandwiched in between them. The lower washer has a spherical face to be used with a spherical housing washer. Assembly and mounting is a simple operation as the parts are separate. They support axial loads in one direction. Clearance is provided in the bore of one of the raceways to allow for alignment. Benefits: Axial loading, ease of mounting and assembly |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 35mm
- Outside Diameter:
- 62mm
- Width:
- 22mm
Technical
Technical
| d | 35mm |
|---|---|
| D | 62mm |
| H1 | 22mm |
| Dynamic load C | 35.1 kN |
| Static load Co | 73.5 kN |
| Fatigue load limit Pu | 2.7 kN |
| Minimum load factor A | 0.028 |
| Reference speed | 4000 rpm |
| Limiting Speed | 5600 rpm |
| Weight | 0.28 kg |
| Seating Washer | U207 |
| d1 | 62mm |
| D1 | 37mm |
| D2 | 48mm |
| D3 | 65mm |
| H | 19.87mm |
| C | 7mm |
| R | 50mm |
| s | 24mm |
| r1r2 min | 1mm |
| da max | 51mm |
| Da max | 48mm |
| ra max | 1mm |
