SKU: 53222?SKF
SKF 53222 Single Thrust Ball Bearing with Spherical Housing Seat U222 110x160x45mm
SKF 53222 Single Thrust Ball Bearing with Spherical Housing Seat U222 110x160x45mm
Regular price
$644.20
ex VAT
Regular price
Sale price
$644.20
ex VAT
In stock
Price Break
10+
$573.34
19+
$541.13
29+
$534.69
39+
$528.24
49+
$521.80
74+
$515.36
99+
$483.15
199+
$476.71
249+
$470.27
499+
$463.82
999+
$450.94
Description
Description
|
SKF Thrust Ball Thrust Bearings Spherical Seat Type: These bearings consist of three parts, a shaft and housing washer that have annular grooves in them and a caged ball bearing assembly that is sandwiched in between them. The lower washer has a spherical face to be used with a spherical housing washer. (shown but available separately). Assembly and mounting is a simple operation as the parts are separate. They support axial loads in one direction. Clearance is provided in the bore of one of the raceways to allow for alignment. Benefits: Axial loading, ease of mounting and assembly |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 110mm
- Outside Diameter:
- 160mm
- Width:
- 45mm
Technical
Technical
| d | 110mm |
|---|---|
| D | 160mm |
| H1 | 45mm |
| Dynamic load C | 130 kN |
| Static load Co | 390 kN |
| Fatigue load limit Pu | 12.5 kN |
| Minimum load factor A | 0.79 |
| Reference speed | 1700 rpm |
| Limiting speed | 2400 rpm |
| Weight | 2.91 kg |
| Seating washer | U222 |
| d1 | 160mm |
| D1 | 113mm |
| D2 | 135mm |
| D3 | 165mm |
| H | 40.2mm |
| C | 14mm |
| R | 125mm |
| s | 65mm |
| r1r2 min | 1.1mm |
| da max | 140mm |
| Da max | 135mm |
| ra max | 1mm |
