SKF 53318 Single Thrust Ball Bearing with Spherical Housing Seat U318 90x155x59mm
SKF 53318 Single Thrust Ball Bearing with Spherical Housing Seat U318 90x155x59mm
Regular price
$802.22
ex VAT
Regular price
Sale price
$802.22
ex VAT
In stock
Price Break
10+
$713.98
19+
$673.86
29+
$665.84
39+
$657.82
49+
$649.80
74+
$641.78
99+
$601.67
199+
$593.64
249+
$585.62
499+
$577.60
999+
$561.55
Description
Description
|
SKF Thrust Ball Thrust Bearings Spherical Seat Type: These bearings consist of three parts, a shaft and housing washer that have annular grooves in them and a caged ball bearing assembly that is sandwiched in between them. The lower washer has a spherical face to be used with a spherical housing washer. (shown but available separately). Assembly and mounting is a simple operation as the parts are separate. They support axial loads in one direction. Clearance is provided in the bore of one of the raceways to allow for alignment. Benefits: Axial loading, ease of mounting and assembly |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 90mm
- Outside Diameter:
- 155mm
- Width:
- 59mm
Technical
Technical
| d | 90mm |
|---|---|
| D | 155mm |
| H1 | 59mm |
| Dynamic load C | 195 kN |
| Static load Co | 500 kN |
| Fatigue load limit Pu | 16.6 kN |
| Minimum load factor A | 1.3 |
| Reference speed | 1500 rpm |
| Limiting speed | 2200 rpm |
| Weight | 4.7 kg |
| Seating washer | U318 |
| d1 | 155mm |
| D1 | 93mm |
| D2 | 120mm |
| D3 | 160mm |
| H | 54.6mm |
| C | 18mm |
| R | 112mm |
| s | 40mm |
| r1r2 min | 1.5mm |
| da max | 129mm |
| Da max | 120mm |
| ra max | 1.5mm |
