SKU: EXF315-SNR
SNR EXF315 Metric Four Bolt Square Cast Iron Flange Housing with 75mm Bore Eccentric Collar Insert - Allow 2-3 Days
SNR EXF315 Metric Four Bolt Square Cast Iron Flange Housing with 75mm Bore Eccentric Collar Insert - Allow 2-3 Days
Regular price
$446.39
ex VAT
Regular price
Sale price
$446.39
ex VAT
In stock
Price Break
5+
$441.93
10+
$424.07
20+
$415.14
50+
$401.75
100+
$392.82
500+
$370.50
1000+
$312.47
Description
Description
|
UCF or SF Series 4 Bolt Square Cast Iron Housings: Bearing units supplied with a fully sealed bearing insert fitted in the cast iron housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
- Brand / Quality:
- SNR - High Quality
- Inside Diameter:
- 75mm
- Style:
- EXF
- Bolt Hole Centres:
- 184mm
Technical
Technical
| --- | Dimensions |
|---|---|
| Shaft diameter d | 75mm |
| A | 66mm |
| A1 | 25mm |
| A2 | 101.7mm |
| B | 74.6mm |
| B1 | 100mm |
| d1 | 113mm |
| e | 39mm |
| J | 184mm |
| L | 236mm |
| N | 25mm |
| S | 37.3mm |
| G | M10x1 |
| --- | Load rating |
| Dynamic load C | 113.36 kN |
| Static load C0 | 76.8 kN |
| --- | Unit information |
| Operating temperature min. | -20°C |
| Operating temperature max. | 100°C |
| Recommended tightening torque for set screw | 64 Nm |
| Mass | 11.29 kg |
