FAG H310 Adaptor Sleeve with Lock Nut and Locking Device for 45mm Shaft
FAG H310 Adaptor Sleeve with Lock Nut and Locking Device for 45mm Shaft
Regular price
$20.43
ex VAT
Regular price
Sale price
$20.43
ex VAT
In stock
Price Break
10+
$18.18
19+
$17.16
29+
$16.96
39+
$16.75
49+
$16.55
74+
$16.34
99+
$15.32
199+
$15.12
249+
$14.91
499+
$14.71
999+
$14.30
Description
Description
|
Adaptor Sleeves: Are the most commonly used components for locating bearings with a tapered bore onto a cylindrical seating. They can be used on plain shafts allowing the bearing to be positioned as required and locked into place or on stepped shafts with a seating ring to set the bearing off a shoulder before locking it into position Benefits: Re-useable, adjustable, positive location, easy to dismount |
- Brand / Quality:
- FAG - High Quality
- Inside Diameter:
- 45mm
- Outside Diameter:
- 70mm
- Width:
- 42mm
Technical
Technical
| --- | Dimensions |
|---|---|
| d1 | 45mm |
| d | 50mm |
| d3 | 70mm |
| B1 | 42mm |
| B2 | 12mm |
| G | Thread 50x1.5mm |
| Weight | 0.29 kg |
| --- | Assembly Parts |
| Sleeve | H310 |
| Nut | KM10 |
| Washer | MB10 |
| --- | Matching Self Aligning Bearings |
| Bearing No. | <a href=advanced_search_result.php?sort=2a&search_in_description=1&keywords=2210K+taper+self+open>2210K</a> |
| Bearing No. | <a href=advanced_search_result.php?sort=2a&search_in_description=1&keywords=1310K+taper+self+open>1310K</a> |
| --- | Matching Spherical Roller Bearings |
| Bearing No. | <a href=advanced_search_result.php?sort=2a&search_in_description=1&keywords=22210K+taper>22210K</a> |
| Bearing No. | <a href=advanced_search_result.php?sort=2a&search_in_description=1&keywords=21310K+taper>21310K</a> |
