SKU: K003
K003 Metric Grub Screw Type Bearing Insert with 17mm Bore 35mm Outside Dia
K003 Metric Grub Screw Type Bearing Insert with 17mm Bore 35mm Outside Dia
Regular price
$10.48
ex VAT
Regular price
Sale price
$10.48
ex VAT
In stock
Price Break
10+
$9.33
19+
$8.80
29+
$8.70
39+
$8.59
49+
$8.49
74+
$8.38
99+
$7.86
199+
$7.76
249+
$7.65
499+
$7.55
999+
$7.34
Description
Description
|
Miniature SB Series Insert: Sealed bearing insert with grub screws to allow tightening against the shaft once fitted.
This insert is typical of those found in housed bearings and has a spherical outer diameter to facilitate removal and re-fitting into a housing, It has a flat back to allow close proximity fitment of shafts and rollers.. |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 17mm
- Outside Diameter:
- 35mm
- Style:
- K
Technical
Technical
| Inside Diameter d | 17mm |
|---|---|
| Outside Diameter D | 35mm |
| Bi | 17.5mm |
| Be | 10mm |
| r | 0.5mm |
| n | 5mm |
| G | 3.5mm |
| W | 23.1mm |
| Grub screw | M4X0.5 |
| Dynamic load | 5978N ~ 609.586 kgf |
| Static load | 3283N ~ 334.773 kgf |
| Weight | 0.06 kg |
