• RHP MFC45 Four Bolt Round Cast Iron Flanged Bearing Unit and 45mm Insert
1 1

SKU: MFC45-RHP

RHP MFC45 Four Bolt Round Cast Iron Flanged Bearing Unit and 45mm Insert

RHP MFC45 Four Bolt Round Cast Iron Flanged Bearing Unit and 45mm Insert
$152.09 ex VAT
$152.09 ex VAT
Sale Sold out

In stock

Price Break
10+ $135.36
19+ $127.76
29+ $126.23
39+ $124.71
49+ $123.19
74+ $121.67
99+ $114.07
199+ $112.55
249+ $111.03
499+ $109.50
999+ $106.46
Request Quotation

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description

RHP MFC Series Heavy Duty 4 Bolt Round Cast Iron Housing Units: Four bolt round cast iron bearing unit supplied with a sealed full width bearing insert fitted and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft after installation.
The insert can be removed from the housings for future replacement as required
Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing ,heavy duty full width bearing insert
Brand / Quality:
RHP - High Quality
Inside Diameter:
45mm
Style:
MFC
Pitch Circle Diameter:
130.18mm
Technical
Bore 45mm
L 155.6mm
H 107.95mm
J 130.18mm
G 10mm
A1 39.67mm
A4 19mm
A5 6.4mm
B 51.59mm
s 19.1mm
d1 62.2mm
Dynamic load 35000 N
Static load 23200 N
Rec max speed 3400 rpm
Weight 2.7 kg
Insert <a href="advanced_search_result.php?keywords=1050-45G+insonly">1050-45G Click Here</a>
Casting group 4
Grease nipple thread 1/4 UNF, 1/4 inch x 28 TPI
