• RHP MFC80 Four Bolt Round Cast Iron Flanged Bearing Unit and 80mm Insert
1 1

SKU: MFC80-RHP

RHP MFC80 Four Bolt Round Cast Iron Flanged Bearing Unit and 80mm Insert

RHP MFC80 Four Bolt Round Cast Iron Flanged Bearing Unit and 80mm Insert
$400.79 ex VAT
$400.79 ex VAT
Sale Sold out

In stock

Price Break
10+ $356.70
19+ $336.66
29+ $332.66
39+ $328.65
49+ $324.64
74+ $320.63
99+ $300.59
199+ $296.58
249+ $292.58
499+ $288.57
999+ $280.55
Request Quotation

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description

RHP MFC Series Heavy Duty 4 Bolt Round Cast Iron Housing Units: Four bolt round cast iron bearing unit supplied with a sealed full width bearing insert fitted and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft after installation.
The insert can be removed from the housings for future replacement as required
Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing ,heavy duty full width bearing insert
Brand / Quality:
RHP - High Quality
Inside Diameter:
80mm
Style:
MFC
Pitch Circle Diameter:
190.5mm
Technical
Bore 80mm
L 222.2mm
H 161.92mm
J 190.5mm
G 16mm
A1 50.8mm
A4 16.7mm
A5 12.7mm
B 82.55mm
s 33.37mm
d1 98.5mm
Dynamic load 71500 N
Static load 54500 N
Rec max speed 2150 rpm
Weight 5.4 kg
Insert <a href="advanced_search_result.php?keywords=1080-80G+insonly">1080-80G Click Here</a>
Casting group 9
Grease nipple thread 1/4 UNF, 1/4 inch x 28 TPI
