SKU: MSF1.3/16-RHP
RHP MSF1-3/16 Imperial Four Bolt Square Cast Iron Flange Housing and 1-3/16 inch Bore Grub Screw Insert
RHP MSF1-3/16 Imperial Four Bolt Square Cast Iron Flange Housing and 1-3/16 inch Bore Grub Screw Insert
Regular price
$87.60
ex VAT
Regular price
Sale price
$87.60
ex VAT
In stock
Price Break
10+
$77.96
19+
$73.58
29+
$72.71
39+
$71.83
49+
$70.96
74+
$70.08
99+
$65.70
199+
$64.82
249+
$63.95
499+
$63.07
999+
$61.32
Description
Description
|
RHP MSF Series Heavy Duty 4 Bolt Square Cast Iron Housings: Bearing units supplied with a full width sealed heavy duty bearing insert fitted in the cast iron housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has two grub screws to allow tightening against the shaft after installation. |
- Brand / Quality:
- RHP - High Quality
- Inside Diameter:
- 30.16mm = 1.187 (1-3/16) inch
- Style:
- MSF
- Bolt Hole Centres:
- 91.999mm = 3.622 inch
Technical
Technical
| Bore | 1-3/16 inch |
|---|---|
| L | 4.626 inch |
| H | 3.752 inch |
| J | 3.622 inch |
| G | 0.5 inch |
| A | 1.236 inch |
| A1 | 1.827 inch |
| A4 | 0.5 inch |
| B | 1.688 inch |
| s | 0.69 inch |
| d1 | 1.838 inch |
| Dynamic load cr | 25700 N |
| Static load Cor | 15300 N |
| Rec max speed | 4500 rpm |
| Weight | 1.7 kg |
| Insert | <a href="advanced_search_result.php?keywords=1035-1-3/16G+insonly">1035-1-3/16G Click Here</a> |
| Casting group | 2 |
| Grease nipple thread | 1/4 UNF, 1/4 inch x 28 TPI |
