SKU: MSF1.3/4-RHP
RHP MSF1-3/4 Imperial Four Bolt Square Cast Iron Flange Housing and 1-3/4 inch Bore Grub Screw Insert
RHP MSF1-3/4 Imperial Four Bolt Square Cast Iron Flange Housing and 1-3/4 inch Bore Grub Screw Insert
Regular price
$140.20
ex VAT
Regular price
Sale price
$140.20
ex VAT
In stock
Price Break
10+
$124.78
19+
$117.77
29+
$116.37
39+
$114.96
49+
$113.56
74+
$112.16
99+
$105.15
199+
$103.75
249+
$102.35
499+
$100.94
999+
$98.14
Description
Description
|
RHP MSF Series Heavy Duty 4 Bolt Square Cast Iron Housings: Bearing units supplied with a full width sealed heavy duty bearing insert fitted in the cast iron housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has two grub screws to allow tightening against the shaft after installation. |
- Brand / Quality:
- RHP - High Quality
- Inside Diameter:
- 44.45mm = 1.75 (1-3/4) inch
- Style:
- MSF
- Bolt Hole Centres:
- 110.998mm = 4.37 inch
Technical
Technical
| Bore | 1-3/4 inch |
|---|---|
| L | 5.626 inch |
| H | 4.563 inch |
| J | 4.37 inch |
| G | 0.625 inch |
| A | 1.563 inch |
| A1 | 2.383 inch |
| A4 | 0.563 inch |
| B | 2.031 inch |
| s | 0.752 inch |
| d1 | 2.449 inch |
| Dynamic load cr | 35000 N |
| Static load Cor | 23200 N |
| Rec max speed | 3400 rpm |
| Weight | 2.8 kg |
| Insert | <a href="advanced_search_result.php?keywords=1050-1-3/4G+insonly">1050-1-3/4G Click Here</a> |
| Casting group | 5 |
| Grease nipple thread | 1/4 UNF, 1/4 inch x 28 TPI |
