SKU: MSF1035-30K-RHP
RHP MSF1035-30K Metric Four Bolt Square Cast Iron Flange Housing and 30mm Bore Taper Sleeve Insert
RHP MSF1035-30K Metric Four Bolt Square Cast Iron Flange Housing and 30mm Bore Taper Sleeve Insert
Regular price
$138.13
ex VAT
Regular price
Sale price
$138.13
ex VAT
In stock
Price Break
10+
$122.94
19+
$116.03
29+
$114.65
39+
$113.27
49+
$111.89
74+
$110.50
99+
$103.60
199+
$102.22
249+
$100.83
499+
$99.45
999+
$96.69
Description
Description
|
RHP MSF Series Heavy Duty 4 Bolt Square Cast Iron Housings: Bearing units supplied with a full width sealed heavy duty bearing insert fitted in the cast iron housing and includes a grease nipple to facilitate re-lubrication. The bearing has a taper bore to accommodate the taper sleeve which is tightened using a lock nut to secure to the shaft after installation, the locknut is subsequently secured with the tab washer. |
- Brand / Quality:
- RHP - High Quality
- Inside Diameter:
- 30mm
- Style:
- MSF
- Bolt Hole Centres:
- 92mm
Technical
Technical
| Bore | 30mm |
|---|---|
| L | 117.5mm |
| H | 95.3mm |
| J | 92mm |
| G | 12mm |
| A | 31.4mm |
| A1 | -mm |
| A4 | 12.7mm |
| B | -mm |
| s | -mm |
| d1 | -mm |
| Dynamic load cr | 25700 N |
| Static load Cor | 15300 N |
| Rec max speed | 4500 rpm |
| Weight | 1.7 kg |
| Insert | <a href="advanced_search_result.php?keywords=1035K+insonly">1035K Click Here</a> |
| Casting group | 2 |
| Grease nipple thread | 1/4 UNF, 1/4 inch x 28 TPI |
