SKU: UCFC.205
UCFC205 Metric Four Bolt Cast Iron Round Flanged Housing with 25mm Insert
UCFC205 Metric Four Bolt Cast Iron Round Flanged Housing with 25mm Insert
Regular price
$17.00
ex VAT
Regular price
Sale price
$17.00
ex VAT
In stock
Price Break
10+
$15.13
19+
$14.28
29+
$14.11
39+
$13.94
49+
$13.77
74+
$13.60
99+
$12.75
199+
$12.58
249+
$12.41
499+
$12.24
999+
$11.90
Description
Description
|
UCFC Series 4 Bolt Round Cast Iron Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the round cast iron housing and includes a grease nipple to facilitate re-lubrication, this style has the benefit of a shouldered back face to facilitate location of the housing prior to fastening in place. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 25mm
- Style:
- UCFC
- Pitch Circle Diameter:
- 90mm
Technical
Technical
| d | 25mm |
|---|---|
| a | 115mm |
| P | 90mm |
| e | 63.6mm |
| i | 10mm |
| L | 27mm |
| s | 12mm |
| j | 6mm |
| k | 7mm |
| g | 21mm |
| f | 70mm |
| z | 29.7mm |
| Bi | 34mm |
| n | 14.3mm |
| Bolt Size | M10 |
| Weight | 0.95 kg |
| Dynamic load | 1100 kgf |
| Static load | 710 kgf |
