UCFC214 Metric Four Bolt Cast Iron Round Flanged Housing with 70mm Insert
UCFC214 Metric Four Bolt Cast Iron Round Flanged Housing with 70mm Insert
Regular price
$119.36
ex VAT
Regular price
Sale price
$119.36
ex VAT
In stock
Price Break
10+
$106.23
19+
$100.26
29+
$99.07
39+
$97.88
49+
$96.68
74+
$95.49
99+
$89.52
199+
$88.33
249+
$87.13
499+
$85.94
999+
$83.55
Description
Description
|
UCFC Series 4 Bolt Round Cast Iron Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the round cast iron housing and includes a grease nipple to facilitate re-lubrication, this style has the benefit of a shouldered back face to facilitate location of the housing prior to fastening in place. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 70mm
- Style:
- UCFC
- Pitch Circle Diameter:
- 177mm
Technical
Technical
| d | 70mm |
|---|---|
| a | 215mm |
| P | 177mm |
| e | 125.1mm |
| i | 17mm |
| L | 54mm |
| s | 19mm |
| j | 14mm |
| k | 18mm |
| g | 40mm |
| f | 150mm |
| z | 61.1mm |
| Bi | 74.6mm |
| n | 30.2mm |
| Bolt Size | M16 |
| Weight | 6.8 kg |
| Dynamic load | 4870 kgf |
| Static load | 3810 kgf |
