SKU: UCFC.215
UCFC215 Metric Four Bolt Cast Iron Round Flanged Housing with 75mm Insert
UCFC215 Metric Four Bolt Cast Iron Round Flanged Housing with 75mm Insert
Regular price
$229.57
ex VAT
Regular price
Sale price
$229.57
ex VAT
In stock
Price Break
10+
$204.32
19+
$192.84
29+
$190.54
39+
$188.25
49+
$185.95
74+
$183.66
99+
$172.18
199+
$169.88
249+
$167.59
499+
$165.29
999+
$160.70
Description
Description
|
UCFC Series 4 Bolt Round Cast Iron Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the round cast iron housing and includes a grease nipple to facilitate re-lubrication, this style has the benefit of a shouldered back face to facilitate location of the housing prior to fastening in place. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 75mm
- Style:
- UCFC
- Pitch Circle Diameter:
- 184mm
Technical
Technical
| d | 75mm |
|---|---|
| a | 220mm |
| P | 184mm |
| e | 130.1mm |
| i | 18mm |
| L | 56mm |
| s | 19mm |
| j | 16mm |
| k | 18mm |
| g | 40mm |
| f | 160mm |
| z | 62.5mm |
| Bi | 77.8mm |
| n | 33.3mm |
| Bolt Size | M16 |
| Weight | 7.3 kg |
| Dynamic load | 5190 kgf |
| Static load | 4190 kgf |
