SKU: UCFG216D1-NTN
NTN UCFG216D1 Metric Four Bolt Square Steel Flange Housing with 80mm Bore Insert - Allow 2-3 Days
NTN UCFG216D1 Metric Four Bolt Square Steel Flange Housing with 80mm Bore Insert - Allow 2-3 Days
Regular price
$1,215.97
ex VAT
Regular price
Sale price
$1,215.97
ex VAT
In stock
Price Break
2+
$1,155.17
5+
$1,094.37
10+
$1,033.57
15+
$972.78
20+
$948.46
30+
$924.14
50+
$802.54
Description
Description
UCFG Series 4 Bolt Square Steel Housings: These bearing units are supplied with a fully sealed bearing insert fitted in the cast iron housing and include a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement if required.
Benefits: Cost-effective bearing/housing assembly, can be re-lubricated, replaceable insert, grub screw fixing
Benefits: Cost-effective bearing/housing assembly, can be re-lubricated, replaceable insert, grub screw fixing
- Brand / Quality:
- NTN - High Quality
- Inside Diameter:
- 80mm
- Style:
- UCFG
- Bolt Hole Centres:
- 165mm
Technical
Technical
| Shaft diameter | 80mm |
|---|---|
| L | 208mm |
| J | 165mm |
| A<sub>2</sub> | 34mm |
| A<sub>1</sub> | 22mm |
| A | 58mm |
| N | 23mm |
| A<sub>0</sub> | 83.3mm |
| B | 82.6mm |
| S | 33.3mm |
| Fixing bolt | M20 |
| Mass | 10 kg |
