NTN UCFL307D1 Metric Two Bolt Oval Cast Iron Flange Housing with 35mm Bore Insert - Allow 2-3 Days
NTN UCFL307D1 Metric Two Bolt Oval Cast Iron Flange Housing with 35mm Bore Insert - Allow 2-3 Days
Regular price
$89.25
ex VAT
Regular price
Sale price
$89.25
ex VAT
In stock
Price Break
5+
$88.36
10+
$84.79
20+
$83.00
50+
$80.33
100+
$78.54
500+
$74.08
1000+
$62.48
Description
Description
UCFL300 Series Heavy Duty 2 Bolt Oval Housings: These heavy-duty bearing units are supplied with a fully sealed bearing insert fitted in the oval cast iron housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts can be removed from the housing for future replacement as required.
Benefits: Can be re-lubricated, replaceable bearing insert, grub screw fixing
- Brand / Quality:
- NTN - High Quality
- Inside Diameter:
- 35mm
- Style:
- UCFL
- Bolt Hole Centres:
- 141mm
Technical
Technical
| --- | Dimensions |
|---|---|
| Shaft diameter | 35mm |
| H | 185mm |
| J | 141mm |
| A<sub>2</sub> | 20mm |
| A<sub>1</sub> | 16mm |
| A | 36mm |
| N | 23mm |
| L | 100mm |
| A<sub>0</sub> | 49mm |
| B | 48mm |
| S | 19mm |
| Fixing bolt | M20 |
| --- | Load rating |
| Dynamic load C<sub>r</sub> | 37 kN |
| Static load C<sub>0r</sub> | 19.1 kN |
| Fatigue load limit C<sub>u</sub> | 1.47 kN |
| --- | Unit information |
| Mass | 1.7 kg |
