SKU: UCFL308D1-NTN
NTN UCFL308D1 Metric Two Bolt Oval Cast Iron Flange Housing with 40mm Bore Insert - Allow 2-3 Days
NTN UCFL308D1 Metric Two Bolt Oval Cast Iron Flange Housing with 40mm Bore Insert - Allow 2-3 Days
Regular price
$118.90
ex VAT
Regular price
Sale price
$118.90
ex VAT
In stock
Price Break
5+
$117.71
10+
$112.96
20+
$110.58
50+
$107.01
100+
$104.63
500+
$98.69
1000+
$83.23
Description
Description
UCFL300 Series Heavy Duty 2 Bolt Oval Housings: These heavy-duty bearing units are supplied with a fully sealed bearing insert fitted in the oval cast iron housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts can be removed from the housing for future replacement as required.
Benefits: Can be re-lubricated, replaceable bearing insert, grub screw fixing
- Brand / Quality:
- NTN - High Quality
- Inside Diameter:
- 40mm
- Style:
- UCFL
- Bolt Hole Centres:
- 158mm
Technical
Technical
| --- | Dimensions |
|---|---|
| Shaft diameter | 40mm |
| H | 200mm |
| J | 158mm |
| A<sub>2</sub> | 23mm |
| A<sub>1</sub> | 17mm |
| A | 40mm |
| N | 23mm |
| L | 112mm |
| A<sub>0</sub> | 56mm |
| B | 52mm |
| S | 19mm |
| Fixing bolt | M20 |
| --- | Load rating |
| Dynamic load C<sub>r</sub> | 45 kN |
| Static load C<sub>0r</sub> | 24 kN |
| Fatigue load limit C<sub>u</sub> | 1.83 kN |
| --- | Unit information |
| Mass | 2.2 kg |
