SKU: UCFS308
UCFS308 Metric Four Bolt Square Cast Iron Flange Housing with 40mm Bore Insert
UCFS308 Metric Four Bolt Square Cast Iron Flange Housing with 40mm Bore Insert
Regular price
$110.99
ex VAT
Regular price
Sale price
$110.99
ex VAT
In stock
Price Break
10+
$98.78
19+
$93.23
29+
$92.12
39+
$91.01
49+
$89.90
74+
$88.79
99+
$83.24
199+
$82.13
249+
$81.02
499+
$79.91
999+
$77.69
Description
Description
UCFS Series 4 Bolt Square Cast Iron Housings: These bearing units are supplied with a fully sealed bearing insert fitted in the cast iron housing and include a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required
Benefits: Cost-effective bearing/housing assembly, can be re-lubricated, replaceable insert, grub screw fixing
Benefits: Cost-effective bearing/housing assembly, can be re-lubricated, replaceable insert, grub screw fixing
- Brand / Quality:
- EU Budget - Economy Quality
- Inside Diameter:
- 40mm
- Style:
- UCFS
- Bolt Hole Centres:
- 112mm
Technical
Technical
| d | 40mm |
|---|---|
| a | 150mm |
| e | 112mm |
| i | 13mm |
| s | 19mm |
| g | 10mm |
| j | 17mm |
| l | 40mm |
| f | 115mm |
| z | 56mm |
| B | 52mm |
| n | 19mm |
| Bolt size | M16 |
| Bearing no | UC308 |
| Housing no | FS308 |
| Weight | 3 kg |
