Challenge / FK UCPX10 Metric Cast Iron Two Bolt Pillow Block Housing with 50mm Bore Insert and Triple Lip Seal Ideal for Agricultural and Outdoor Use
Challenge / FK UCPX10 Metric Cast Iron Two Bolt Pillow Block Housing with 50mm Bore Insert and Triple Lip Seal Ideal for Agricultural and Outdoor Use
Regular price
$138.95
ex VAT
Regular price
Sale price
$138.95
ex VAT
Equivalent to: UCPX.10
In stock
Price Break
10+
$123.67
19+
$116.72
29+
$115.33
39+
$113.94
49+
$112.55
74+
$111.16
99+
$104.21
199+
$102.82
249+
$101.43
499+
$100.04
999+
$97.27
Description
Description
UCPX Cast Iron Two Bolt Pillow Block Housing: These medium-duty bearing units are fitted with a triple lip seal in a cast iron housing and includes a grease nipple to facilitate re-lubrication. These bearings are perfect for agricultural applications where the bearings are exposed to contamination. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required.
Benefits: High tolerance to harsh environments, cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing
Equivalent: UCPX.10
- Brand / Quality:
- Challenge / FK - Good Quality
- Inside Diameter:
- 50mm
- Style:
- UCPX
- Bolt Hole Centres:
- 171mm
Technical
Technical
| Shaft Diameter d | 50mm |
|---|---|
| Casting Centre Line Height h | 63.5mm |
| Casting Length a | 241mm |
| Recommended Bolt Centres l | 171mm |
| Casting Width b | 73mm |
| Slot Length s<sub>2</sub> | 36mm |
| Slot Width s<sub>1</sub> | 20mm |
| Foot Height g | 27mm |
| Overall Height w | 126mm |
| Bearing Insert Width Bi | 55.6mm |
| Back of Bearing to Centre Line n | 22.2mm |
| Bolt Size | M16 |
| Grub Screws x 2 | M10X1.25mm |
| Load Rating (Dynamic) | 3400kg |
| Load Rating (Static) | 2550kg |
| Max Speed | 1800 rev/min |
| Working Temperature | -30°C to +120°C |
| Insert No | UCX10 |
| Housing No | PX10 |
