Challenge / FK UCPX14 Metric Cast Iron Two Bolt Pillow Block Housing with 70mm Bore Insert and Triple Lip Seal Ideal for Agricultural and Outdoor Use
Challenge / FK UCPX14 Metric Cast Iron Two Bolt Pillow Block Housing with 70mm Bore Insert and Triple Lip Seal Ideal for Agricultural and Outdoor Use
Regular price
$366.08
ex VAT
Regular price
Sale price
$366.08
ex VAT
Equivalent to: UCPX.14
In stock
Price Break
10+
$325.81
19+
$307.51
29+
$303.85
39+
$300.19
49+
$296.52
74+
$292.86
99+
$274.56
199+
$270.90
249+
$267.24
499+
$263.58
999+
$256.26
Description
Description
UCPX Cast Iron Two Bolt Pillow Block Housing: These medium-duty bearing units are fitted with a triple lip seal in a cast iron housing and includes a grease nipple to facilitate re-lubrication. These bearings are perfect for agricultural applications where the bearings are exposed to contamination. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required.
Benefits: High tolerance to harsh environments, cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing
Equivalent: UCPX.14
- Brand / Quality:
- Challenge / FK - Good Quality
- Inside Diameter:
- 70mm
- Style:
- UCPX
- Bolt Hole Centres:
- 229mm
Technical
Technical
| Shaft Diameter d | 70mm |
|---|---|
| Casting Centre Line Height h | 88.9mm |
| Casting Length a | 330mm |
| Recommended Bolt Centres l | 229mm |
| Casting Width b | 89mm |
| Slot Length s<sub>2</sub> | 50mm |
| Slot Width s<sub>1</sub> | 27mm |
| Foot Height g | 35mm |
| Overall Height w | 171mm |
| Bearing Insert Width Bi | 77.8mm |
| Back of Bearing to Centre Line n | 33.3mm |
| Bolt Size | M22 |
| Grub Screws x 2 | M12X1.50mm |
| Load Rating (Dynamic) | 5190kg |
| Load Rating (Static) | 4190kg |
| Max Speed | 1300 rev/min |
| Working Temperature | -30°C to +120°C |
| Insert No | UCX14 |
| Housing No | PX14 |
